YT Industries Izzo Blaze (2021) - Geometry

💰 YT Industries Izzo Blaze (2021) im Preisvergleich bei MTB News Daily Deals

Compare these geometries with each other

Die Tabelle lässt sich verschieben.
Modell YT Industries Izzo Blaze (2021) YT Industries Izzo Blaze (2021) YT Industries Izzo Blaze (2021) YT Industries Izzo Blaze (2021) YT Industries Izzo Blaze (2021)
Frame Size/Setup S M L XL XXL
Typ Mountainbike Mountainbike Mountainbike Mountainbike Mountainbike
Wheel Size 29″ 29″ 29″ 29″ 29″ 29″ 29″ 29″ 29″ 29″
Reach 424 mm 424 mm 445 mm 445 mm 467 mm 467 mm 487 mm 487 mm 508 mm 508 mm
Stack 607 mm 607 mm 616 mm 616 mm 625 mm 625 mm 639 mm 639 mm 648 mm 648 mm
STR 1.43 1.43 1.38 1.38 1.34 1.34 1.31 1.31 1.28 1.28
Reach+
Stack+
Frame RAD 740 mm 740 mm 760 mm 760 mm 780 mm 780 mm 803 mm 803 mm 823 mm 823 mm
Frame RAAD 34.9° 34.9° 35.8° 35.8° 36.8° 36.8° 37.3° 37.3° 38.1° 38.1°
Front-Center
Head Angle 65.5° 66° 65.5° 66° 65.5° 66° 65.5° 66° 65.5° 66°
Seat Angle, effective 76.5° 77° 76.5° 77° 76.5° 77° 76.5° 77° 76.5° 77°
Seat Angle, real 69° 69.5° 69° 69.5° 69° 69.5° 69° 69.5° 69° 69.5°
Top Tube Length 568 mm 568 mm 593 mm 593 mm 618 mm 618 mm 643 mm 643 mm 668 mm 668 mm
Top Tube Length (horizontal)
Head Tube Length 95 mm 95 mm 105 mm 105 mm 115 mm 115 mm 130 mm 130 mm 140 mm 140 mm
Seat Tube Length 400 mm 400 mm 425 mm 425 mm 450 mm 450 mm 475 mm 475 mm 500 mm 500 mm
Standover Height 734 mm 734 mm 727 mm 727 mm 721 mm 721 mm 716 mm 716 mm 734 mm 734 mm
Chainstay Length 432 mm 432 mm 432 mm 432 mm 432 mm 432 mm 432 mm 432 mm 432 mm 432 mm
Wheelbase 1,170 mm 1,170 mm 1,195 mm 1,195 mm 1,221 mm 1,221 mm 1,251 mm 1,251 mm 1,277 mm 1,277 mm
FC2RC 1.71 1.71 1.77 1.77 1.83 1.83 1.90 1.90 1.96 1.96
Bottom Bracket Drop 36 mm 31 mm 36 mm 31 mm 36 mm 31 mm 36 mm 31 mm 36 mm 31 mm
Bottom Bracket Height 338 mm 343 mm 338 mm 343 mm 338 mm 343 mm 338 mm 343 mm 338 mm 343 mm
Fork installation height
Fork offset
Trail
Travel (rear) 130 mm 130 mm 130 mm 130 mm 130 mm 130 mm 130 mm 130 mm 130 mm 130 mm
Travel (front) 140 mm 140 mm 140 mm 140 mm 140 mm 140 mm 140 mm 140 mm 140 mm 140 mm
