YT Industries Jeffsy Primus 26 (2022) - Geometry

Compare these geometries with each other

The table can be moved.
Modell YT Industries Jeffsy Primus 26 (2022)
Frame Size/Setup One Size
Typ Mountainbike
Wheel Size 26″ 26″
Reach 397 mm 397 mm
Stack 549 mm 549 mm
STR 1,38 1,38
Head Angle 66° 65.5°
Seat Angle, effective 77° 76.5°
Seat Angle, real 72.5° 72°
Top Tube Length 533 mm 533 mm
Top Tube Length (horizontal)
Head Tube Length
Seat Tube Length 355 mm 355 mm
Standover Height 635 mm 635 mm
Chainstay Length 415 mm 415 mm
Wheelbase 1.105 mm 1.105 mm
Bottom Bracket Drop 4 mm 5 mm
Bottom Bracket Height 349 mm 340 mm
Fork installation height
Fork offset
Fork caster
Travel (rear) 130 mm 130 mm
Travel (front) 140 mm 140 mm
