YT Industries Jeffsy 29 (2019) - Geometry

Compare these geometries with each other

The table can be moved.
Modell YT Industries Jeffsy 29 (2019) YT Industries Jeffsy 29 (2019) YT Industries Jeffsy 29 (2019) YT Industries Jeffsy 29 (2019) YT Industries Jeffsy 29 (2019)
Frame Size/Setup S M L XL XXL
Typ Mountainbike Mountainbike Mountainbike Mountainbike Mountainbike
Wheel Size 29″ 29″ 29″ 29″ 29″ 29″ 29″ 29″ 29″ 29″
Reach 430 mm 430 mm 450 mm 450 mm 470 mm 470 mm 490 mm 490 mm 510 mm 510 mm
Stack 618 mm 618 mm 622 mm 622 mm 627 mm 627 mm 636 mm 636 mm 640 mm 640 mm
STR 1,44 1,44 1,38 1,38 1,33 1,33 1,30 1,30 1,25 1,25
Reach+
Stack+
Front-Center
Head Angle 66° 66.5° 66° 66.5° 66.5° 66° 66.5° 66° 66.5° 66°
Seat Angle, effective 77° 77.5° 77° 77.5° 77.5° 77° 77.5° 77° 77.5° 77°
Seat Angle, real 0° 0° 0° 0° 0° 0° 0° 0° 0° 0°
Top Tube Length 572 mm 572 mm 593 mm 593 mm 615 mm 615 mm 638 mm 638 mm 660 mm 660 mm
Top Tube Length (horizontal)
Head Tube Length 100 mm 100 mm 105 mm 105 mm 110 mm 110 mm 120 mm 120 mm 125 mm 125 mm
Seat Tube Length 400 mm 400 mm 415 mm 415 mm 435 mm 435 mm 460 mm 460 mm 485 mm 485 mm
Standover Height
Chainstay Length 435 mm 435 mm 435 mm 435 mm 435 mm 435 mm 440 mm 440 mm 440 mm 440 mm
Wheelbase 1.174 mm 1.174 mm 1.196 mm 1.196 mm 1.218 mm 1.218 mm 1.247 mm 1.247 mm 1.269 mm 1.269 mm
Bottom Bracket Drop 32 mm 34 mm 32 mm 34 mm 34 mm 32 mm 34 mm 32 mm 34 mm 32 mm
Bottom Bracket Height 344 mm 352 mm 344 mm 352 mm 352 mm 344 mm 352 mm 344 mm 352 mm 344 mm
Fork installation height 0 mm 0 mm 0 mm 0 mm 0 mm 0 mm 0 mm 0 mm 0 mm 0 mm
Fork offset
Fork caster
Travel (rear)
Travel (front)
