Compare these geometries with each other
| Modell | YT Industries Decoy 29 (2022) | YT Industries Decoy 29 (2022) | YT Industries Decoy 29 (2022) | YT Industries Decoy 29 (2022) | YT Industries Decoy 29 (2022) |
|---|---|---|---|---|---|
| Frame Size/Setup | S | M | L | XL | XXL |
| Typ | Mountainbike | Mountainbike | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 29″ 29″ | 29″ 29″ | 29″ 29″ | 29″ 29″ | 29″ 29″ |
| Reach | 423 mm 423 mm | 443 mm 443 mm | 463 mm 463 mm | 463 mm 463 mm | 503 mm 503 mm |
| Stack | 614 mm 614 mm | 619 mm 619 mm | 623 mm 623 mm | 632 mm 632 mm | 641 mm 641 mm |
| STR | 1,45 1,45 | 1,40 1,40 | 1,35 1,35 | 1,37 1,37 | 1,27 1,27 |
| Front-Center | |||||
| Head Angle | 65.5° 66.3° | 65.5° 66.3° | 65.5° 66.3° | 65.5° 66.3° | 65.5° 66.3° |
| Seat Angle, effective | 77° 77.5° | 77° 77.5° | 77° 77.5° | 77° 77.5° | 77° 77.5° |
| Seat Angle, real | |||||
| Top Tube Length | 565 mm 565 mm | 587 mm 587 mm | 608 mm 608 mm | 631 mm 631 mm | 654 mm 654 mm |
| Top Tube Length (horizontal) | |||||
| Head Tube Length | 95 mm 95 mm | 100 mm 100 mm | 105 mm 105 mm | 115 mm 115 mm | 125 mm 125 mm |
| Seat Tube Length | 400 mm 400 mm | 420 mm 420 mm | 445 mm 445 mm | 470 mm 470 mm | 495 mm 495 mm |
| Standover Height | |||||
| Chainstay Length | 458 mm 458 mm | 458 mm 458 mm | 458 mm 458 mm | 458 mm 458 mm | 458 mm 458 mm |
| Wheelbase | 1.197 mm 1.197 mm | 1.219 mm 1.219 mm | 1.241 mm 1.241 mm | 1.265 mm 1.265 mm | 1.289 mm 1.289 mm |
| Bottom Bracket Drop | |||||
| Bottom Bracket Height | 338 mm 345 mm | 338 mm 345 mm | 338 mm 345 mm | 338 mm 345 mm | |
| Fork installation height | |||||
| Fork offset | 51 mm 51 mm | 51 mm 51 mm | 51 mm 51 mm | 51 mm 51 mm | 51 mm 51 mm |
| Fork caster | |||||
| Travel (rear) | 145 mm 145 mm | 145 mm 145 mm | 145 mm 145 mm | 145 mm 145 mm | 145 mm 145 mm |
| Travel (front) | 150 mm 150 mm | 150 mm 150 mm | 150 mm 150 mm | 150 mm 150 mm | 150 mm 150 mm |
