Wilier Garda Disc (2022) - Geometry
Compare these geometries with each other
Die Tabelle lässt sich verschieben.
| Modell | Wilier Garda Disc (2022) | Wilier Garda Disc (2022) | Wilier Garda Disc (2022) | Wilier Garda Disc (2022) | Wilier Garda Disc (2022) | Wilier Garda Disc (2022) |
|---|---|---|---|---|---|---|
| Frame Size/Setup | XS | S | M | L | XL | XXL |
| Typ | Rennrad | Rennrad | Rennrad | Rennrad | Rennrad | Rennrad |
| Wheel Size | 28″ / 700C | 28″ / 700C | 28″ / 700C | 28″ / 700C | 28″ / 700C | 28″ / 700C |
| Reach | 373 mm | 378 mm | 383 mm | 388 mm | 393 mm | 398 mm |
| Stack | 515 mm | 531 mm | 548 mm | 566 mm | 584 mm | 602 mm |
| STR | 1.38 | 1.40 | 1.43 | 1.46 | 1.49 | 1.51 |
| Reach+ | ||||||
| Stack+ | ||||||
| Frame RAD | 636 mm | 652 mm | 669 mm | 686 mm | 704 mm | 722 mm |
| Frame RAAD | 35.9° | 35.4° | 34.9° | 34.4° | 33.9° | 33.5° |
| Front-Center | ||||||
| Head Angle | 70.5° | 71.7° | 72.15° | 72.65° | 72.8° | 73.1° |
| Seat Angle, effective | ||||||
| Seat Angle, real | 75.2° | 74.6° | 74° | 73.5° | 73° | 72.6° |
| Top Tube Length | ||||||
| Top Tube Length (horizontal) | 511 mm | 526 mm | 541 mm | 556 mm | 572 mm | 587 mm |
| Head Tube Length | 112 mm | 125 mm | 144 mm | 161 mm | 179 mm | 197 mm |
| Seat Tube Length | 385 mm | 410 mm | 435 mm | 465 mm | 495 mm | 525 mm |
| Standover Height | ||||||
| Chainstay Length | 409 mm | 409 mm | 411 mm | 411 mm | 411 mm | 411 mm |
| Wheelbase | 981 mm | 981 mm | 990 mm | 996 mm | 1,009 mm | 1,016 mm |
| FC2RC | 1.40 | 1.40 | 1.41 | 1.42 | 1.45 | 1.47 |
| Bottom Bracket Drop | ||||||
| Bottom Bracket Height | ||||||
| Fork installation height | ||||||
| Fork offset | ||||||
| Trail | ||||||
| Travel (rear) | ||||||
| Travel (front) |
Notes
Posts about this Bike
Report error
Please describe the error as accurately as possible. We will look at it and try to fix it as soon as possible!
Auch Felgen gebremstes Modell erhältlich.
