Wilier Filante SLR (2021) - Geometry
Compare these geometries with each other
The table can be moved.
| Modell | Wilier Filante SLR (2021) | Wilier Filante SLR (2021) | Wilier Filante SLR (2021) | Wilier Filante SLR (2021) | Wilier Filante SLR (2021) | Wilier Filante SLR (2021) |
|---|---|---|---|---|---|---|
| Frame Size/Setup | XS | S | M | L | XL | XXL |
| Typ | Rennrad | Rennrad | Rennrad | Rennrad | Rennrad | Rennrad |
| Wheel Size | 28″ / 700C | 28″ / 700C | 28″ / 700C | 28″ / 700C | 28″ / 700C | 28″ / 700C |
| Reach | 380 mm | 384 mm | 388 mm | 391 mm | 395 mm | 399 mm |
| Stack | 505 mm | 521 mm | 538 mm | 555 mm | 571 mm | 587 mm |
| STR | 1,33 | 1,36 | 1,39 | 1,42 | 1,45 | 1,47 |
| Reach+ | ||||||
| Stack+ | ||||||
| Front-Center | ||||||
| Head Angle | 70.8° | 72° | 72.5° | 73° | 73° | 73.5° |
| Seat Angle, effective | 75.2° | 74.5° | 74° | 73.5° | 73° | 72.5° |
| Seat Angle, real | ||||||
| Top Tube Length | 515 mm | 530 mm | 543 mm | 556 mm | 570 mm | 583 mm |
| Top Tube Length (horizontal) | ||||||
| Head Tube Length | 104 mm | 119 mm | 135 mm | 154 mm | 166 mm | 181 mm |
| Seat Tube Length | 432 mm | 462 mm | 482 mm | 502 mm | 522 mm | 542 mm |
| Standover Height | ||||||
| Chainstay Length | 407 mm | 407 mm | 408 mm | 410 mm | 411 mm | 411 mm |
| Wheelbase | 981 mm | 984 mm | 990 mm | 997 mm | 1.002 mm | 1.006 mm |
| Bottom Bracket Drop | ||||||
| Bottom Bracket Height | ||||||
| Fork installation height | ||||||
| Fork offset | ||||||
| Fork caster | ||||||
| Travel (rear) | ||||||
| Travel (front) |
