Compare these geometries with each other
| Modell | Trek Session 29" (2022) | Trek Session 29" (2022) | Trek Session 29" (2022) |
|---|---|---|---|
| Frame Size/Setup | R1 | R2 | R3 |
| Typ | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 29″ 29″ | 29″ 29″ | 29″ 29″ |
| Reach | 446.8 mm 440 mm | 471.6 mm 465 mm | 499.4 mm 493 mm |
| Stack | 633.9 mm 638.6 mm | 633.7 mm 638.6 mm | 633.5 mm 638.6 mm |
| STR | 1,42 1,45 | 1,34 1,37 | 1,27 1,30 |
| Front-Center | |||
| Head Angle | 63.6° 63° | 63.6° 63° | 63.6° 63° |
| Seat Angle, effective | 77.1° 76.5° | 77.1° 76.5° | 77.1° 76.5° |
| Seat Angle, real | 61.6° 61° | 61.6° 61° | 61.6° 61° |
| Top Tube Length | 585.8 mm 587.3 mm | 616.8 mm 618.3 mm | 651.8 mm 653.3 mm |
| Top Tube Length (horizontal) | |||
| Head Tube Length | 117 mm 117 mm | 117 mm 117 mm | 117 mm 117 mm |
| Seat Tube Length | 425 mm 425 mm | 450 mm 450 mm | 450 mm 450 mm |
| Standover Height | 754.6 mm 747 mm | 758.7 mm 751 mm | 756.8 mm 749 mm |
| Chainstay Length | 435.1 mm 439 mm | 441.1 mm 445 mm | 448.2 mm 452 mm |
| Wheelbase | 1.251 mm 1.255 mm | 1.282 mm 1.286 mm | 1.317 mm 1.321 mm |
| Bottom Bracket Drop | 13.9 mm 22.5 mm | 13.9 mm 22.5 mm | 13.9 mm 22.5 mm |
| Bottom Bracket Height | 358.6 mm 350 mm | 358.6 mm 350 mm | 358.6 mm 350 mm |
| Fork installation height | 600 mm 600 mm | 600 mm 600 mm | 600 mm 600 mm |
| Fork offset | 56 mm 56 mm | 56 mm 56 mm | 56 mm 56 mm |
| Fork caster | |||
| Travel (rear) | 204 mm 200 mm | 204 mm 200 mm | 204 mm 200 mm |
| Travel (front) | 200 mm 200 mm | 200 mm 200 mm | 200 mm 200 mm |
