Compare these geometries with each other
| Modell | Trek Powerfly FS 7 (2021) | Trek Powerfly FS 7 (2021) | Trek Powerfly FS 7 (2021) | Trek Powerfly FS 7 (2021) | Trek Powerfly FS 7 (2021) |
|---|---|---|---|---|---|
| Frame Size/Setup | XS | S | M | L | XL |
| Typ | Mountainbike | Mountainbike | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 27,5″ / 650B | 27,5″ / 650B | 29″ | 29″ | 29″ |
| Reach | 405 mm | 415 mm | 430 mm | 460 mm | 485 mm |
| Stack | 599 mm | 599 mm | 637 mm | 646 mm | 646 mm |
| STR | 1,48 | 1,44 | 1,48 | 1,40 | 1,33 |
| Front-Center | |||||
| Head Angle | 66.5° | 66.5° | 66.5° | 66.5° | 66.5° |
| Seat Angle, effective | 76° | 76° | 76° | 76° | 76° |
| Seat Angle, real | |||||
| Top Tube Length | 554 mm | 564 mm | 589 mm | 621 mm | 646 mm |
| Top Tube Length (horizontal) | |||||
| Head Tube Length | 140 mm | 140 mm | 130 mm | 140 mm | 140 mm |
| Seat Tube Length | 368 mm | 395 mm | 420 mm | 450 mm | 500 mm |
| Standover Height | 691 mm | 691 mm | 712 mm | 716 mm | 713 mm |
| Chainstay Length | 468 mm | 468 mm | 470 mm | 470 mm | 470 mm |
| Wheelbase | 1.170 mm | 1.180 mm | 1.206 mm | 1.240 mm | 1.265 mm |
| Bottom Bracket Drop | |||||
| Bottom Bracket Height | |||||
| Fork installation height | |||||
| Fork offset | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Fork caster | |||||
| Travel (rear) | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm |
| Travel (front) | 100 mm | 100 mm | 120 mm | 120 mm | 120 mm |
