Compare these geometries with each other
| Modell | Thömus Lightrider E2 Pro (2021) | Thömus Lightrider E2 Pro (2021) | Thömus Lightrider E2 Pro (2021) | Thömus Lightrider E2 Pro (2021) |
|---|---|---|---|---|
| Frame Size/Setup | S | M | L | XL |
| Typ | Mountainbike | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 29″ | 29″ | 29″ | 29″ |
| Reach | 410 mm | 441 mm | 470 mm | 495 mm |
| Stack | 619 mm | 628 mm | 637 mm | 641 mm |
| STR | 1,51 | 1,42 | 1,36 | 1,29 |
| Front-Center | ||||
| Head Angle | 65.1° | 65.1° | 65.1° | 65.1° |
| Seat Angle, effective | 75° | 74.6° | 74.3° | 74.1° |
| Seat Angle, real | ||||
| Top Tube Length | 576 mm | 613 mm | 649 mm | 678 mm |
| Top Tube Length (horizontal) | ||||
| Head Tube Length | 100 mm | 110 mm | 120 mm | 125 mm |
| Seat Tube Length | 400 mm | 440 mm | 480 mm | 500 mm |
| Standover Height | ||||
| Chainstay Length | 455 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | ||||
| Bottom Bracket Drop | ||||
| Bottom Bracket Height | 355 mm | 355 mm | 355 mm | 355 mm |
| Fork installation height | ||||
| Fork offset | ||||
| Fork caster | ||||
| Travel (rear) | 160 mm | 160 mm | 160 mm | 160 mm |
| Travel (front) | 170 mm | 170 mm | 170 mm | 170 mm |
