Specialized Turbo Tero (2022) - Geometry
Compare these geometries with each other
Die Tabelle lässt sich verschieben.
| Modell | Specialized Turbo Tero (2022) | Specialized Turbo Tero (2022) | Specialized Turbo Tero (2022) | Specialized Turbo Tero (2022) |
|---|---|---|---|---|
| Frame Size/Setup | S | M | L | XL |
| Typ | Mountainbike | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 29″ | 29″ | 29″ | 29″ |
| Reach | 405 mm | 426 mm | 446 mm | 462 mm |
| Stack | 637 mm | 651 mm | 664 mm | 687 mm |
| STR | 1,57 | 1,53 | 1,49 | 1,49 |
| Reach+ | ||||
| Stack+ | ||||
| Front-Center | ||||
| Head Angle | 66.4° | 66.4° | 66.4° | 66.4° |
| Seat Angle, effective | 73.9° | 73.4° | 72.9° | 72.4° |
| Seat Angle, real | ||||
| Top Tube Length | ||||
| Top Tube Length (horizontal) | 589 mm | 610 mm | 650 mm | 680 mm |
| Head Tube Length | 135 mm | 150 mm | 165 mm | 190 mm |
| Seat Tube Length | 400 mm | 450 mm | 460 mm | 500 mm |
| Standover Height | 773 mm | 807 mm | 807 mm | 835 mm |
| Chainstay Length | 470.4 mm | 470.4 mm | 470.4 mm | 470.4 mm |
| Wheelbase | 1.173 mm | 1.200 mm | 1.226 mm | 1.252 mm |
| Bottom Bracket Drop | 57 mm | 57 mm | 57 mm | 57 mm |
| Bottom Bracket Height | 313 mm | 313 mm | 313 mm | 313 mm |
| Fork installation height | 516 mm | 516 mm | 516 mm | 516 mm |
| Fork offset | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | ||||
| Travel (rear) | ||||
| Travel (front) | 110 mm | 110 mm | 110 mm | 110 mm |
