Specialized Enduro (2020) - Geometry

Compare these geometries with each other

Die Tabelle lässt sich verschieben.
Modell Specialized Enduro (2020) Specialized Enduro (2020) Specialized Enduro (2020) Specialized Enduro (2020)
Frame Size/Setup S2 S3 S4 S5
Typ Mountainbike Mountainbike Mountainbike Mountainbike
Wheel Size 29″ 29″ 29″ 29″ 29″ 29″ 29″ 29″
Reach 437 mm 437 mm 464 mm 464 mm 487 mm 487 mm 511 mm 511 mm
Stack 616 mm 616 mm 620 mm 620 mm 629 mm 629 mm 638 mm 638 mm
STR 1,41 1,41 1,34 1,34 1,29 1,29 1,25 1,25
Reach+
Stack+
Front-Center
Head Angle 63.9° 64.3° 63.9° 64.3° 63.9° 64.3° 63.9° 64.3°
Seat Angle, effective 75.6° 76° 75.6° 76° 75.6° 76° 75.6° 76°
Seat Angle, real
Top Tube Length 591 mm 591 mm 619 mm 619 mm 644 mm 644 mm 670 mm 670 mm
Top Tube Length (horizontal)
Head Tube Length 95 mm 95 mm 100 mm 100 mm 110 mm 110 mm 120 mm 120 mm
Seat Tube Length 400 mm 400 mm 420 mm 420 mm 440 mm 440 mm 465 mm 465 mm
Standover Height
Chainstay Length 442 mm 442 mm 442 mm 442 mm 442 mm 442 mm 442 mm 442 mm
Wheelbase 1.217 mm 1.217 mm 1.246 mm 1.246 mm 1.274 mm 1.274 mm 1.302 mm 1.302 mm
FC2RC 1,75 1,75 1,82 1,82 1,88 1,88 1,95 1,95
Bottom Bracket Drop 28 mm 21 mm 28 mm 21 mm 28 mm 21 mm 28 mm 21 mm
Bottom Bracket Height 347 mm 354 mm 347 mm 354 mm 347 mm 354 mm 347 mm 354 mm
Fork installation height
Fork offset 46 mm 46 mm 46 mm 46 mm 46 mm 46 mm 46 mm 46 mm
Trail
Travel (rear) 170 mm 170 mm 170 mm 170 mm 170 mm 170 mm 170 mm 170 mm
Travel (front) 170 mm 170 mm 170 mm 170 mm 170 mm 170 mm 170 mm 170 mm
