Compare these geometries with each other
| Modell | Simplon Cirex SL 120 (2022) | Simplon Cirex SL 120 (2022) | Simplon Cirex SL 120 (2022) | Simplon Cirex SL 120 (2022) |
|---|---|---|---|---|
| Frame Size/Setup | S | M | L | XL |
| Typ | Mountainbike | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 29″ | 29″ | 29″ | 29″ |
| Reach | 421 mm | 446 mm | 471 mm | 496 mm |
| Stack | 596 mm | 608 mm | 620 mm | 632 mm |
| STR | 1,42 | 1,36 | 1,32 | 1,27 |
| Front-Center | ||||
| Head Angle | 67.4° | 67.4° | 67.4° | 67.4° |
| Seat Angle, effective | 75.4° | 75.4° | 75.4° | 75.4° |
| Seat Angle, real | ||||
| Top Tube Length | ||||
| Top Tube Length (horizontal) | 577 mm | 605 mm | 627 mm | 655 mm |
| Head Tube Length | 89 mm | 102 mm | 115 mm | 128 mm |
| Seat Tube Length | 390 mm | 425 mm | 465 mm | 510 mm |
| Standover Height | 757 mm | 757 mm | 757 mm | 757 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1.134 mm | 1.164 mm | 1.194 mm | 1.224 mm |
| Bottom Bracket Drop | 40 mm | 40 mm | 40 mm | 40 mm |
| Bottom Bracket Height | ||||
| Fork installation height | 532 mm | 532 mm | 532 mm | 532 mm |
| Fork offset | 44 mm | 44 mm | 44 mm | 44 mm |
| Fork caster | ||||
| Travel (rear) | 115 mm | 115 mm | 115 mm | 115 mm |
| Travel (front) | 120 mm | 120 mm | 120 mm | 120 mm |
