Scor 4060 Z ST (2022) - Geometry
Compare these geometries with each other
Die Tabelle lässt sich verschieben.
| Modell | Scor 4060 Z ST (2022) | Scor 4060 Z ST (2022) | Scor 4060 Z ST (2022) | Scor 4060 Z ST (2022) |
|---|---|---|---|---|
| Frame Size/Setup | S | M | L | XL |
| Typ | Mountainbike | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 29″ 29″ | 29″ 29″ | 29″ 29″ | 29″ 29″ |
| Reach | 440 mm 436 mm | 465 mm 461 mm | 490 mm 485 mm | 520 mm 516 mm |
| Stack | 597 mm 599 mm | 608 mm 611 mm | 622 mm 625 mm | 633 mm 636 mm |
| STR | 1.36 1.37 | 1.31 1.33 | 1.27 1.29 | 1.22 1.23 |
| Reach+ | ||||
| Stack+ | ||||
| Frame RAD | 742 mm 741 mm | 765 mm 765 mm | 792 mm 791 mm | 819 mm 819 mm |
| Frame RAAD | 36.4° 36.1° | 37.4° 37° | 38.2° 37.8° | 39.4° 39.1° |
| Front-Center | ||||
| Head Angle | 64.5° 65.5° | 64.5° 65.5° | 64.5° 65.5° | 64.5° 65.5° |
| Seat Angle, effective | 78.5° 78° | 78.5° 78° | 78.5° 78° | 78.5° 78° |
| Seat Angle, real | 69.4° 69° | 69.4° 69° | 69.4° 69° | 69.4° 69° |
| Top Tube Length | 560 mm 561 mm | 589 mm 590 mm | 620 mm 621 mm | 654 mm 655 mm |
| Top Tube Length (horizontal) | ||||
| Head Tube Length | 87 mm 87 mm | 99 mm 99 mm | 115 mm 115 mm | 127 mm 127 mm |
| Seat Tube Length | 400 mm 400 mm | 425 mm 425 mm | 440 mm 440 mm | 470 mm 470 mm |
| Standover Height | ||||
| Chainstay Length | 433 mm 433 mm | 433 mm 433 mm | 433 mm 433 mm | 433 mm 433 mm |
| Wheelbase | 1,198 mm 1,185 mm | 1,223 mm 1,210 mm | 1,248 mm 1,235 mm | 1,278 mm 1,265 mm |
| FC2RC | 1.77 1.74 | 1.82 1.79 | 1.88 1.85 | 1.95 1.92 |
| Bottom Bracket Drop | 31 mm 29 mm | 31 mm 29 mm | 31 mm 29 mm | 31 mm 29 mm |
| Bottom Bracket Height | 338 mm 340 mm | 338 mm 340 mm | 338 mm 340 mm | 338 mm 340 mm |
| Fork installation height | ||||
| Fork offset | 44 mm 44 mm | 44 mm 44 mm | 44 mm 44 mm | 44 mm 44 mm |
| Trail | ||||
| Travel (rear) | 140 mm 140 mm | 140 mm 140 mm | 140 mm 140 mm | 140 mm 140 mm |
| Travel (front) | 150 mm 150 mm | 150 mm 150 mm | 150 mm 150 mm | 150 mm 150 mm |
