Scor 0020 (2022) - Geometry

Compare these geometries with each other

The table can be moved.
Modell Scor 0020 (2022)
Frame Size/Setup 20
Typ Mountainbike
Wheel Size 20″
Reach 305 mm
Stack 412 mm
STR 1,35
Head Angle 68°
Seat Angle, effective
Seat Angle, real
Top Tube Length 431 mm
Top Tube Length (horizontal)
Head Tube Length 105 mm
Seat Tube Length 275 mm
Standover Height 490 mm
Chainstay Length 342 mm
Wheelbase 833 mm
Bottom Bracket Drop 40 mm
Bottom Bracket Height
Fork installation height
Fork offset 35 mm
Fork caster
Travel (rear)
Travel (front)
