Sciu Aspen 29"+ 27,5" Enduro Mix (2022) - Geometry
Compare these geometries with each other
Die Tabelle lässt sich verschieben.
| Modell | Sciu Aspen 29"+ 27,5" Enduro Mix (2022) | Sciu Aspen 29"+ 27,5" Enduro Mix (2022) | Sciu Aspen 29"+ 27,5" Enduro Mix (2022) |
|---|---|---|---|
| Frame Size/Setup | M | L | XL |
| Typ | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | Mullet 29/27,5 | Mullet 29/27,5 | Mullet 29/27,5 |
| Reach | 439.6 mm | 470.9 mm | 491.9 mm |
| Stack | 625.9 mm | 632.3 mm | 642.6 mm |
| STR | 1.42 | 1.34 | 1.31 |
| Reach+ | |||
| Stack+ | |||
| Frame RAD | 765 mm | 788 mm | 809 mm |
| Frame RAAD | 35.1° | 36.7° | 37.4° |
| Front-Center | |||
| Head Angle | 63.5° | 63.5° | 63.5° |
| Seat Angle, effective | 75.5° | 75.5° | 75.5° |
| Seat Angle, real | |||
| Top Tube Length | |||
| Top Tube Length (horizontal) | 599.3 mm | 631.8 mm | 655.1 mm |
| Head Tube Length | 95 mm | 100 mm | 110 mm |
| Seat Tube Length | 410 mm | 445 mm | 485 mm |
| Standover Height | 761 mm | 777 mm | 795 mm |
| Chainstay Length | 434.2 mm | 434.2 mm | 434.2 mm |
| Wheelbase | 1,226 mm | 1,259 mm | 1,279 mm |
| FC2RC | 1.82 | 1.90 | 1.95 |
| Bottom Bracket Drop | 46.6 mm | 46.8 mm | 46.8 mm |
| Bottom Bracket Height | |||
| Fork installation height | |||
| Fork offset | |||
| Trail | |||
| Travel (rear) | 155 mm | 155 mm | 155 mm |
| Travel (front) | 170 mm | 170 mm | 170 mm |
