Compare these geometries with each other
| Modell | Santa Cruz Chameleon (2022) | Santa Cruz Chameleon (2022) | Santa Cruz Chameleon (2022) | Santa Cruz Chameleon (2022) |
|---|---|---|---|---|
| Frame Size/Setup | S | M | L | XL |
| Typ | Mountainbike | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 29″ 29″ Mullet 29/27,5 Mullet 29/27,5 | 29″ 29″ Mullet 29/27,5 Mullet 29/27,5 | 29″ 29″ Mullet 29/27,5 Mullet 29/27,5 | 29″ 29″ Mullet 29/27,5 Mullet 29/27,5 |
| Reach | 420 mm 420 mm 420 mm 420 mm | 445 mm 445 mm 445 mm 445 mm | 465 mm 465 mm 465 mm 465 mm | 490 mm 490 mm 490 mm 490 mm |
| Stack | 620.1 mm 620.1 mm 620.1 mm 620.1 mm | 629.2 mm 629.2 mm 629.2 mm 629.2 mm | 638.2 mm 638.2 mm 638.2 mm 638.2 mm | 647.3 mm 647.3 mm 647.3 mm 647.3 mm |
| STR | 1,48 1,48 1,48 1,48 | 1,41 1,41 1,41 1,41 | 1,37 1,37 1,37 1,37 | 1,32 1,32 1,32 1,32 |
| Front-Center | ||||
| Head Angle | 65° 65° 65° 65° | 65° 65° 65° 65° | 65° 65° 65° 65° | 65° 65° 65° 65° |
| Seat Angle, effective | 74.1° 74.1° 74.1° 74.1° | 74.3° 74.3° 74.3° 74.3° | 74.4° 74.4° 74.4° 74.4° | 74.6° 74.6° 74.6° 74.6° |
| Seat Angle, real | 74.1° 74.1° 74.1° 74.1° | 74.3° 74.3° 74.3° 74.3° | 74.4° 74.4° 74.4° 74.4° | 74.6° 74.6° 74.6° 74.6° |
| Top Tube Length | ||||
| Top Tube Length (horizontal) | 596.1 mm 596.1 mm 596.1 mm 596.1 mm | 621.3 mm 621.3 mm 621.3 mm 621.3 mm | 643.4 mm 643.4 mm 643.4 mm 643.4 mm | 668.8 mm 668.8 mm 668.8 mm 668.8 mm |
| Head Tube Length | 100 mm 100 mm 100 mm 100 mm | 110 mm 110 mm 110 mm 110 mm | 120 mm 120 mm 120 mm 120 mm | 130 mm 130 mm 130 mm 130 mm |
| Seat Tube Length | 380 mm 380 mm 380 mm 380 mm | 405 mm 405 mm 405 mm 405 mm | 430 mm 430 mm 430 mm 430 mm | 460 mm 460 mm 460 mm 460 mm |
| Standover Height | 682 mm 682 mm 682 mm 682 mm | 682 mm 682 mm 682 mm 682 mm | 686 mm 686 mm 686 mm 686 mm | 708 mm 708 mm 708 mm 708 mm |
| Chainstay Length | 425 mm 437 mm 425 mm 437 mm | 425 mm 437 mm 425 mm 437 mm | 425 mm 437 mm 425 mm 437 mm | 425 mm 437 mm 425 mm 437 mm |
| Wheelbase | 1.154 mm 1.154 mm 1.154 mm 1.154 mm | 1.183 mm 1.183 mm 1.183 mm 1.183 mm | 1.207 mm 1.207 mm 1.207 mm 1.207 mm | 1.237 mm 1.237 mm 1.237 mm 1.237 mm |
| Bottom Bracket Drop | 40 mm 40 mm 56 mm 56 mm | 40 mm 40 mm 56 mm 56 mm | 40 mm 40 mm 56 mm 56 mm | 40 mm 40 mm 56 mm 56 mm |
| Bottom Bracket Height | 315 mm 315 mm 315 mm 315 mm | 315 mm 315 mm 315 mm 315 mm | 315 mm 315 mm 315 mm 315 mm | 315 mm 315 mm 315 mm 315 mm |
| Fork installation height | ||||
| Fork offset | ||||
| Fork caster | ||||
| Travel (rear) | 0 mm 0 mm 0 mm 0 mm | 0 mm 0 mm 0 mm 0 mm | 0 mm 0 mm 0 mm 0 mm | 0 mm 0 mm 0 mm 0 mm |
| Travel (front) | 130 mm 130 mm 130 mm 130 mm | 130 mm 130 mm 130 mm 130 mm | 130 mm 130 mm 130 mm 130 mm | 130 mm 130 mm 130 mm 130 mm |
