Compare these geometries with each other
| Modell | Ridley Noah Disc (2022) | Ridley Noah Disc (2022) | Ridley Noah Disc (2022) | Ridley Noah Disc (2022) | Ridley Noah Disc (2022) | Ridley Noah Disc (2022) |
|---|---|---|---|---|---|---|
| Frame Size/Setup | XXS | XS | S | M | L | XL |
| Typ | Rennrad | Rennrad | Rennrad | Rennrad | Rennrad | Rennrad |
| Wheel Size | 28″ / 700C | 28″ / 700C | 28″ / 700C | 28″ / 700C | 28″ / 700C | 28″ / 700C |
| Reach | 375 mm | 378 mm | 385 mm | 393 mm | 401 mm | 409 mm |
| Stack | 493 mm | 516 mm | 541 mm | 565 mm | 591 mm | 616 mm |
| STR | 1,31 | 1,37 | 1,41 | 1,44 | 1,47 | 1,51 |
| Front-Center | ||||||
| Head Angle | 71.5° | 72° | 73° | 73.5° | 73.5° | 74° |
| Seat Angle, effective | ||||||
| Seat Angle, real | 74.5° | 74° | 73.5° | 73° | 72.5° | 72.5° |
| Top Tube Length | ||||||
| Top Tube Length (horizontal) | 512 mm | 526 mm | 545 mm | 565 mm | 587 mm | 603 mm |
| Head Tube Length | 95 mm | 117 mm | 140 mm | 164 mm | 194 mm | 218 mm |
| Seat Tube Length | 430 mm | 455 mm | 480 mm | 505 mm | 530 mm | 555 mm |
| Standover Height | ||||||
| Chainstay Length | 405 mm | 405 mm | 405 mm | 405 mm | 408 mm | 408 mm |
| Wheelbase | 969 mm | 975 mm | 977 mm | 987 mm | 1.007 mm | 1.017 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 66 mm | 66 mm | 63 mm | 63 mm |
| Bottom Bracket Height | ||||||
| Fork installation height | ||||||
| Fork offset | ||||||
| Fork caster | ||||||
| Travel (rear) | ||||||
| Travel (front) |
