Compare these geometries with each other
| Modell | Radon Bikes Render (2022) | Radon Bikes Render (2022) | Radon Bikes Render (2022) |
|---|---|---|---|
| Frame Size/Setup | M | L | XL |
| Typ | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 29″ | 29″ | 29″ |
| Reach | 436 mm | 456 mm | 473 mm |
| Stack | 620 mm | 629 mm | 637 mm |
| STR | 1,42 | 1,38 | 1,35 |
| Front-Center | |||
| Head Angle | 65.1° | 65.1° | 65.1° |
| Seat Angle, effective | 75.1° | 75.1° | 75.1° |
| Seat Angle, real | |||
| Top Tube Length | 592 mm | 615 mm | 637 mm |
| Top Tube Length (horizontal) | |||
| Head Tube Length | 107 mm | 117 mm | 132 mm |
| Seat Tube Length | 425 mm | 455 mm | 490 mm |
| Standover Height | 781 mm | 781 mm | 781 mm |
| Chainstay Length | 458 mm | 458 mm | 458 mm |
| Wheelbase | 1.220 mm | 1.244 mm | 1.267 mm |
| Bottom Bracket Drop | 24.7 mm | 24.7 mm | 24.7 mm |
| Bottom Bracket Height | |||
| Fork installation height | |||
| Fork offset | |||
| Fork caster | |||
| Travel (rear) | 140 mm | 140 mm | 140 mm |
| Travel (front) | 160 mm | 160 mm | 160 mm |
