Prime Rocket (2021) - Geometry
Compare these geometries with each other
The table can be moved.
| Modell | Prime Rocket (2021) | Prime Rocket (2021) | Prime Rocket (2021) |
|---|---|---|---|
| Frame Size/Setup | M | L | XL |
| Typ | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 29″ | 29″ | 29″ |
| Reach | 455 mm | 475 mm | 500 mm |
| Stack | 628 mm | 632 mm | 637 mm |
| STR | 1,38 | 1,33 | 1,27 |
| Reach+ | |||
| Stack+ | |||
| Front-Center | |||
| Head Angle | 63.5° | 63.5° | 63.5° |
| Seat Angle, effective | |||
| Seat Angle, real | 75° | 75.5° | 76° |
| Top Tube Length | |||
| Top Tube Length (horizontal) | |||
| Head Tube Length | 110 mm | 115 mm | 120 mm |
| Seat Tube Length | 415 mm | 435 mm | 455 mm |
| Standover Height | |||
| Chainstay Length | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1.275 mm | 1.298 mm | 1.325 mm |
| Bottom Bracket Drop | 15 mm | 15 mm | 15 mm |
| Bottom Bracket Height | 356 mm | 356 mm | 356 mm |
| Fork installation height | |||
| Fork offset | |||
| Fork caster | |||
| Travel (rear) | 195 mm | 195 mm | 195 mm |
| Travel (front) | 200 mm | 200 mm | 200 mm |
