Compare these geometries with each other
| Modell | Pivot Shuttle SL (2023) | Pivot Shuttle SL (2023) | Pivot Shuttle SL (2023) | Pivot Shuttle SL (2023) |
|---|---|---|---|---|
| Frame Size/Setup | S | M | L | XL |
| Typ | Mountainbike | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 29″ 29″ | 29″ 29″ | 29″ 29″ | 29″ 29″ |
| Reach | 435 mm 439 mm | 465 mm 469 mm | 478 mm 482 mm | 500 mm 504 mm |
| Stack | 610 mm 607 mm | 626 mm 622 mm | 630 mm 626 mm | 642 mm 638 mm |
| STR | 1,40 1,38 | 1,35 1,33 | 1,32 1,30 | 1,28 1,27 |
| Front-Center | ||||
| Head Angle | 65° 65.5° | 65° 65.5° | 65° 65.5° | 65° 65.4° |
| Seat Angle, effective | 76° 76.5° | 76° 76.5° | 76° 76.5° | 76.8° 77.2° |
| Seat Angle, real | ||||
| Top Tube Length | 568 mm 597 mm | 632 mm 631 mm | 646 mm 645 mm | 660 mm 659 mm |
| Top Tube Length (horizontal) | ||||
| Head Tube Length | 95 mm 95 mm | 112 mm 112 mm | 117 mm 117 mm | 130 mm 130 mm |
| Seat Tube Length | 368 mm 368 mm | 394 mm 394 mm | 432 mm 432 mm | 470 mm 470 mm |
| Standover Height | 665 mm 674 mm | 668 mm 677 mm | 674 mm 682 mm | 678 mm 687 mm |
| Chainstay Length | 432 mm 430 mm | 432 mm 430 mm | 434 mm 432 mm | 438 mm 436 mm |
| Wheelbase | 1.186 mm 1.185 mm | 1.223 mm 1.222 mm | 1.240 mm 1.239 mm | 1.272 mm 1.271 mm |
| Bottom Bracket Drop | 27 mm 21 mm | 27 mm 21 mm | 27 mm 21 mm | 27 mm 21 mm |
| Bottom Bracket Height | 347 mm 352 mm | 347 mm 352 mm | 347 mm 352 mm | 347 mm 352 mm |
| Fork installation height | ||||
| Fork offset | ||||
| Fork caster | ||||
| Travel (rear) | 140 mm 140 mm | 140 mm 140 mm | 140 mm 140 mm | 140 mm 140 mm |
| Travel (front) | 150 mm 150 mm | 150 mm 150 mm | 150 mm 150 mm | 150 mm 150 mm |
