Pivot Point (2021) - Geometry

Compare these geometries with each other

The table can be moved.
Modell Pivot Point (2021)
Frame Size/Setup MD
Typ Mountainbike
Wheel Size 26″
Reach 428.8 mm
Stack 551.3 mm
STR 1,29
Head Angle 68.5°
Seat Angle, effective
Seat Angle, real 72°
Top Tube Length 605 mm
Top Tube Length (horizontal)
Head Tube Length 110 mm
Seat Tube Length 320 mm
Standover Height
Chainstay Length 385 mm
Wheelbase 1.061 mm
Bottom Bracket Drop
Bottom Bracket Height 325 mm
Fork installation height
Fork offset
Fork caster
Travel (rear)
Travel (front)
