Orbea Rise SL (2024) - Geometry
Compare these geometries with each other
Die Tabelle lässt sich verschieben.
| Modell | Orbea Rise SL (2024) | Orbea Rise SL (2024) | Orbea Rise SL (2024) | Orbea Rise SL (2024) |
|---|---|---|---|---|
| Frame Size/Setup | S | M | L | XL |
| Typ | Mountainbike | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 29″ | 29″ | 29″ | 29″ |
| Reach | 440 mm | 465 mm | 490 mm | 515 mm |
| Stack | 609 mm | 614 mm | 623 mm | 632 mm |
| STR | 1.38 | 1.32 | 1.27 | 1.23 |
| Reach+ | ||||
| Stack+ | ||||
| Frame RAD | 751 mm | 770 mm | 793 mm | 815 mm |
| Frame RAAD | 35.8° | 37.1° | 38.2° | 39.2° |
| Front-Center | ||||
| Head Angle | 65.5° | 65.5° | 65.5° | 65.5° |
| Seat Angle, effective | ||||
| Seat Angle, real | 78° | 78° | 78° | 78° |
| Top Tube Length | ||||
| Top Tube Length (horizontal) | 610 mm | 614 mm | 620 mm | 647 mm |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 120 mm |
| Seat Tube Length | 405 mm | 415 mm | 430 mm | 460 mm |
| Standover Height | ||||
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1,193 mm | 1,220 mm | 1,249 mm | 1,279 mm |
| FC2RC | 1.71 | 1.77 | 1.84 | 1.91 |
| Bottom Bracket Drop | 37 mm | 37 mm | 37 mm | 37 mm |
| Bottom Bracket Height | ||||
| Fork installation height | 554 mm | 554 mm | 554 mm | 554 mm |
| Fork offset | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | ||||
| Travel (rear) | 140 mm | 140 mm | 140 mm | 140 mm |
| Travel (front) | 140 mm | 140 mm | 140 mm | 140 mm |
