Orbea Rise (2021) - Geometry
Compare these geometries with each other
The table can be moved.
| Modell | Orbea Rise (2021) | Orbea Rise (2021) | Orbea Rise (2021) | Orbea Rise (2021) |
|---|---|---|---|---|
| Frame Size/Setup | S | M | L | XL |
| Typ | Mountainbike | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 29″ | 29″ | 29″ | 29″ |
| Reach | 425 mm | 450 mm | 474 mm | 500 mm |
| Stack | 604 mm | 613 mm | 627 mm | 646 mm |
| STR | 1,42 | 1,36 | 1,32 | 1,29 |
| Reach+ | ||||
| Stack+ | ||||
| Front-Center | ||||
| Head Angle | 66° | 66° | 66° | 66° |
| Seat Angle, effective | 77° | 77° | 77° | 77° |
| Seat Angle, real | ||||
| Top Tube Length | 565 mm | 592 mm | 619 mm | 649 mm |
| Top Tube Length (horizontal) | ||||
| Head Tube Length | 95 mm | 105 mm | 120 mm | 140 mm |
| Seat Tube Length | 381 mm | 419 mm | 457 mm | 508 mm |
| Standover Height | ||||
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1.170 mm | 1.199 mm | 1.229 mm | 1.264 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Bottom Bracket Height | 336 mm | 336 mm | 336 mm | 336 mm |
| Fork installation height | ||||
| Fork offset | ||||
| Fork caster | ||||
| Travel (rear) | 140 mm | 140 mm | 140 mm | 140 mm |
| Travel (front) | 150 mm | 150 mm | 150 mm | 150 mm |
