Compare these geometries with each other
| Modell | Nukeproof Reactor 290 Carbon (2021) | Nukeproof Reactor 290 Carbon (2021) | Nukeproof Reactor 290 Carbon (2021) |
|---|---|---|---|
| Frame Size/Setup | Large | Medium | X-Large |
| Typ | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 29″ 29″ | 29″ 29″ | 29″ 29″ |
| Reach | 480 mm 480 mm | 451 mm 451 mm | 514 mm 514 mm |
| Stack | 620 mm 620 mm | 615 mm 615 mm | 625 mm 625 mm |
| STR | 1,29 1,29 | 1,36 1,36 | 1,22 1,22 |
| Front-Center | |||
| Head Angle | 65.5° 66° | 65.5° 66° | 65.5° 66° |
| Seat Angle, effective | 75° 75.5° | 75° 75.5° | 75° 75.5° |
| Seat Angle, real | 70.5° 71° | 70.5° 71° | 70.5° 71° |
| Top Tube Length | |||
| Top Tube Length (horizontal) | 640 mm 640 mm | 610 mm 610 mm | 675 mm 675 mm |
| Head Tube Length | 110 mm 110 mm | 105 mm 105 mm | 115 mm 115 mm |
| Seat Tube Length | 458 mm 458 mm | 420 mm 420 mm | 508 mm 508 mm |
| Standover Height | 744 mm | 736 mm | 769 mm |
| Chainstay Length | 440 mm 440 mm | 440 mm 440 mm | 440 mm 440 mm |
| Wheelbase | 1.235 mm 1.235 mm | 1.205 mm 1.205 mm | 1.271 mm 1.271 mm |
| Bottom Bracket Drop | 39 mm 33 mm | 39 mm 33 mm | 39 mm 33 mm |
| Bottom Bracket Height | 330 mm 336 mm | 330 mm 336 mm | 330 mm 336 mm |
| Fork installation height | 554 mm 554 mm | 554 mm 554 mm | 554 mm 554 mm |
| Fork offset | 44 mm 44 mm | 44 mm 44 mm | 44 mm 44 mm |
| Fork caster | |||
| Travel (rear) | 130 mm 130 mm | 130 mm 130 mm | 130 mm 130 mm |
| Travel (front) | 140 mm 140 mm | 140 mm 140 mm | 140 mm 140 mm |
