Nukeproof Reactor 290 (2021) - Geometry
Compare these geometries with each other
Die Tabelle lässt sich verschieben.
| Modell | Nukeproof Reactor 290 (2021) | Nukeproof Reactor 290 (2021) | Nukeproof Reactor 290 (2021) |
|---|---|---|---|
| Frame Size/Setup | Medium | Large | X-Large |
| Typ | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 29″ 29″ | 29″ 29″ | 29″ 29″ |
| Reach | 451 mm 451 mm | 480 mm 480 mm | 514 mm 514 mm |
| Stack | 615 mm 615 mm | 620 mm 620 mm | 625 mm 625 mm |
| STR | 1.36 1.36 | 1.29 1.29 | 1.22 1.22 |
| Reach+ | |||
| Stack+ | |||
| Frame RAD | 763 mm 763 mm | 784 mm 784 mm | 809 mm 809 mm |
| Frame RAAD | 36.3° 36.3° | 37.7° 37.7° | 39.4° 39.4° |
| Front-Center | 762.5 mm 762.5 mm | 792 mm 792 mm | 830 mm 830 mm |
| Head Angle | 66° 65.5° | 66° 65.5° | 66° 65.5° |
| Seat Angle, effective | 75.5° 75° | 75.5° 75° | 75.5° 75° |
| Seat Angle, real | 71° 70.5° | 71° 70.5° | 71° 70.5° |
| Top Tube Length | |||
| Top Tube Length (horizontal) | 610 mm 610 mm | 640 mm 640 mm | 675 mm 675 mm |
| Head Tube Length | 105 mm 105 mm | 110 mm 110 mm | 115 mm 115 mm |
| Seat Tube Length | 420 mm 420 mm | 458 mm 458 mm | 508 mm 508 mm |
| Standover Height | 736 mm 736 mm | 744 mm 744 mm | 769 mm 769 mm |
| Chainstay Length | 440 mm 440 mm | 440 mm 440 mm | 440 mm 440 mm |
| Wheelbase | 1,205 mm 1,205 mm | 1,235 mm 1,235 mm | 1,271 mm 1,271 mm |
| FC2RC | 1.74 1.74 | 1.81 1.81 | 1.89 1.89 |
| Bottom Bracket Drop | 33 mm 36 mm | 33 mm 36 mm | 33 mm 36 mm |
| Bottom Bracket Height | 336 mm 330 mm | 336 mm 330 mm | 336 mm 330 mm |
| Fork installation height | 554 mm 554 mm | 554 mm 554 mm | 554 mm 554 mm |
| Fork offset | 44 mm 44 mm | 44 mm 44 mm | 44 mm 44 mm |
| Trail | |||
| Travel (rear) | 130 mm 130 mm | 130 mm 130 mm | 130 mm 130 mm |
| Travel (front) | 140 mm 140 mm | 140 mm 140 mm | 140 mm 140 mm |
