Nukeproof Giga 290 (2021) - Geometry

Compare these geometries with each other

The table can be moved.
Modell Nukeproof Giga 290 (2021) Nukeproof Giga 290 (2021) Nukeproof Giga 290 (2021) Nukeproof Giga 290 (2021) Nukeproof Giga 290 (2021)
Frame Size/Setup S M L XL XXL
Typ Mountainbike Mountainbike Mountainbike Mountainbike Mountainbike
Wheel Size 29″ 29″ 29″ 29″ 29″
Reach 430 mm 455 mm 475 mm 495 mm 515 mm
Stack 622.26 mm 622.26 mm 631.25 mm 640.24 mm 640.24 mm
STR 1,45 1,37 1,33 1,29 1,24
Reach+
Stack+
Front-Center
Head Angle 63.5° 63.5° 63.5° 63.5° 63.5°
Seat Angle, effective 77.75° 77.75° 78° 78° 78°
Seat Angle, real 72° 72° 72.5° 72.5° 72.5°
Top Tube Length 565.11 mm 590.11 mm 609.18 mm 631.09 mm 653 mm
Top Tube Length (horizontal)
Head Tube Length 100 mm 100 mm 110 mm 120 mm 130 mm
Seat Tube Length 380 mm 410 mm 440 mm 470 mm 500 mm
Standover Height 702.58 mm 710.09 mm 729.88 mm 734.48 mm 750.59 mm
Chainstay Length 445 mm 445 mm 445 mm 445 mm 445 mm
Wheelbase 1.216 mm 1.241 mm 1.265 mm 1.290 mm 1.314 mm
Bottom Bracket Drop 25 mm 25 mm 25 mm 25 mm 25 mm
Bottom Bracket Height 350 mm 350 mm 350 mm 350 mm 350 mm
Fork installation height 591 mm 591 mm 591 mm 591 mm 591 mm
Fork offset 42 mm 42 mm 42 mm 42 mm 42 mm
Fork caster
Travel (rear) 170 mm 170 mm 170 mm 170 mm 170 mm
Travel (front) 180 mm 180 mm 180 mm 180 mm 180 mm
