Compare these geometries with each other
| Modell | Nukeproof Dissent 297 (2022) | Nukeproof Dissent 297 (2022) | Nukeproof Dissent 297 (2022) | Nukeproof Dissent 297 (2022) |
|---|---|---|---|---|
| Frame Size/Setup | S | M | L | XL |
| Typ | Mountainbike | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | Mullet 29/27,5 Mullet 29/27,5 Mullet 29/27,5 | Mullet 29/27,5 Mullet 29/27,5 Mullet 29/27,5 | Mullet 29/27,5 Mullet 29/27,5 Mullet 29/27,5 | Mullet 29/27,5 Mullet 29/27,5 Mullet 29/27,5 |
| Reach | 425 mm 425 mm 425 mm | 440 mm 440 mm 440 mm | 460 mm 460 mm 460 mm | 480 mm 480 mm 480 mm |
| Stack | 631 mm 631 mm 631 mm | 631 mm 631 mm 631 mm | 631 mm 631 mm 631 mm | 631 mm 631 mm 631 mm |
| STR | 1,48 1,48 1,48 | 1,43 1,43 1,43 | 1,37 1,37 1,37 | 1,31 1,31 1,31 |
| Front-Center | ||||
| Head Angle | 63° 63° 63° | 63° 63° 63° | 63° 63° 63° | 63° 63° 63° |
| Seat Angle, effective | 76° 76° 76° | 76° 76° 76° | 76° 76° 76° | 76° 76° 76° |
| Seat Angle, real | ||||
| Top Tube Length | ||||
| Top Tube Length (horizontal) | 560 mm 560 mm 560 mm | 590 mm 590 mm 590 mm | 610 mm 610 mm 610 mm | 630 mm 630 mm 630 mm |
| Head Tube Length | 110 mm 110 mm 110 mm | 110 mm 110 mm 110 mm | 110 mm 110 mm 110 mm | 110 mm 110 mm 110 mm |
| Seat Tube Length | 405 mm 405 mm 405 mm | 405 mm 405 mm 405 mm | 405 mm 405 mm 405 mm | 405 mm 405 mm 405 mm |
| Standover Height | 669.5 mm 669.5 mm 669.5 mm | 667.9 mm 667.9 mm 667.9 mm | 676.9 mm 676.9 mm 676.9 mm | 675.9 mm 675.9 mm 675.9 mm |
| Chainstay Length | 445 mm 440 mm 435 mm | 445 mm 440 mm 435 mm | 445 mm 440 mm 435 mm | 445 mm 440 mm 435 mm |
| Wheelbase | 1.239 mm 1.234 mm 1.229 mm | 1.259 mm 1.254 mm 1.249 mm | 1.279 mm 1.274 mm 1.269 mm | 1.299 mm 1.294 mm 1.289 mm |
| Bottom Bracket Drop | 20 mm 20 mm 20 mm | 20 mm 20 mm 20 mm | 20 mm 20 mm 20 mm | 20 mm 20 mm 20 mm |
| Bottom Bracket Height | 357.5 mm 357.5 mm 357.5 mm | 357.5 mm 357.5 mm 357.5 mm | 357.5 mm 357.5 mm 357.5 mm | 357.5 mm 357.5 mm 357.5 mm |
| Fork installation height | ||||
| Fork offset | 46 mm 46 mm 46 mm | 46 mm 46 mm 46 mm | 46 mm 46 mm 46 mm | 46 mm 46 mm 46 mm |
| Fork caster | ||||
| Travel (rear) | 200 mm 200 mm 200 mm | 200 mm 200 mm 200 mm | 200 mm 200 mm 200 mm | 200 mm 200 mm 200 mm |
| Travel (front) | 200 mm 200 mm 200 mm | 200 mm 200 mm 200 mm | 200 mm 200 mm 200 mm | 200 mm 200 mm 200 mm |
