Compare these geometries with each other
| Modell | Nox Hybrid XC Tour (Brose) (2022) | Nox Hybrid XC Tour (Brose) (2022) | Nox Hybrid XC Tour (Brose) (2022) | Nox Hybrid XC Tour (Brose) (2022) |
|---|---|---|---|---|
| Frame Size/Setup | S | M | L | XL |
| Typ | Sonstiges | Sonstiges | Sonstiges | Sonstiges |
| Wheel Size | 27,5″ / 650B 27,5″ / 650B | 27,5″ / 650B 27,5″ / 650B | 27,5″ / 650B 27,5″ / 650B | 27,5″ / 650B 27,5″ / 650B |
| Reach | 416 mm 416 mm | 424 mm 424 mm | 444 mm 444 mm | 464 mm 464 mm |
| Stack | 632 mm 632 mm | 632 mm 632 mm | 642 mm 642 mm | 642 mm 642 mm |
| STR | 1,52 1,52 | 1,49 1,49 | 1,45 1,45 | 1,38 1,38 |
| Front-Center | ||||
| Head Angle | 67.2° 67.2° | 67.2° 67.2° | 67.2° 67.2° | 67.2° 67.2° |
| Seat Angle, effective | 74.7° 74.7° | 74.7° 74.7° | 74.7° 74.7° | 74.7° 74.7° |
| Seat Angle, real | ||||
| Top Tube Length | 588 mm 588 mm | 596 mm 596 mm | 619 mm 619 mm | 639 mm 639 mm |
| Top Tube Length (horizontal) | ||||
| Head Tube Length | 125 mm 125 mm | 125 mm 125 mm | 135 mm 135 mm | 135 mm 135 mm |
| Seat Tube Length | 396 mm 396 mm | 418 mm 418 mm | 453 mm 453 mm | 481 mm 481 mm |
| Standover Height | 788 mm 788 mm | 789 mm 789 mm | 792 mm 792 mm | 793 mm 793 mm |
| Chainstay Length | 469 mm 454 mm | 469 mm 454 mm | 469 mm 454 mm | 469 mm 454 mm |
| Wheelbase | 1.179 mm 1.164 mm | 1.187 mm 1.172 mm | 1.210 mm 1.195 mm | 1.230 mm 1.215 mm |
| Bottom Bracket Drop | 46 mm 46 mm | 46 mm 46 mm | 46 mm 46 mm | 46 mm 46 mm |
| Bottom Bracket Height | ||||
| Fork installation height | ||||
| Fork offset | ||||
| Fork caster | ||||
| Travel (rear) | ||||
| Travel (front) | 120 mm 120 mm | 120 mm 120 mm | 120 mm 120 mm | 120 mm 120 mm |
