Compare these geometries with each other
| Modell | Norco Sight VLT Alu/Carbon (2022) | Norco Sight VLT Alu/Carbon (2022) | Norco Sight VLT Alu/Carbon (2022) | Norco Sight VLT Alu/Carbon (2022) |
|---|---|---|---|---|
| Frame Size/Setup | S | M | L | XL |
| Typ | Mountainbike | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 29″ | 29″ | 29″ | 29″ |
| Reach | 425 mm | 455 mm | 485 mm | 515 mm |
| Stack | 616 mm | 625 mm | 634 mm | 643 mm |
| STR | 1,45 | 1,37 | 1,31 | 1,25 |
| Front-Center | ||||
| Head Angle | 64° | 64° | 64° | 64° |
| Seat Angle, effective | 77° | 77.3° | 77.7° | 78° |
| Seat Angle, real | ||||
| Top Tube Length | ||||
| Top Tube Length (horizontal) | 567 mm | 596 mm | 624 mm | 652 mm |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Seat Tube Length | 395 mm | 415 mm | 440 mm | 455 mm |
| Standover Height | ||||
| Chainstay Length | 462 mm | 462 mm | 462 mm | 462 mm |
| Wheelbase | 1.224 mm | 1.258 mm | 1.292 mm | 1.327 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm | 25 mm |
| Bottom Bracket Height | 350 mm | 350 mm | 350 mm | 350 mm |
| Fork installation height | ||||
| Fork offset | 44 mm | 44 mm | 44 mm | 44 mm |
| Fork caster | ||||
| Travel (rear) | 150 mm | 150 mm | 150 mm | 150 mm |
| Travel (front) | 160 mm | 160 mm | 160 mm | 160 mm |
