Compare these geometries with each other
| Modell | Norco Sight 27,5 (2021) | Norco Sight 27,5 (2021) | Norco Sight 27,5 (2021) | Norco Sight 27,5 (2021) |
|---|---|---|---|---|
| Frame Size/Setup | S | M | L | XL |
| Typ | Mountainbike | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 27,5″ / 650B | 27,5″ / 650B | 27,5″ / 650B | 27,5″ / 650B |
| Reach | 425 mm | 455 mm | 485 mm | 515 mm |
| Stack | 585 mm | 594 mm | 603 mm | 612 mm |
| STR | 1,38 | 1,31 | 1,24 | 1,19 |
| Front-Center | ||||
| Head Angle | 63.5° | 63.5° | 63.5° | 63.5° |
| Seat Angle, effective | 77° | 77.3° | 77.7° | 78° |
| Seat Angle, real | ||||
| Top Tube Length | 560 mm | 588 mm | 617 mm | 645 mm |
| Top Tube Length (horizontal) | ||||
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Seat Tube Length | 370 mm | 395 mm | 435 mm | 465 mm |
| Standover Height | ||||
| Chainstay Length | 430 mm | 435 mm | 440 mm | 445 mm |
| Wheelbase | 1.180 mm | 1.220 mm | 1.259 mm | 1.299 mm |
| Bottom Bracket Drop | 15 mm | 15 mm | 15 mm | 15 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm | 342 mm |
| Fork installation height | 552 mm | 552 mm | 552 mm | 552 mm |
| Fork offset | 37 mm | 37 mm | 37 mm | 37 mm |
| Fork caster | ||||
| Travel (rear) | 150 mm | 150 mm | 150 mm | 150 mm |
| Travel (front) | 160 mm | 160 mm | 160 mm | 160 mm |
