Compare these geometries with each other
| Modell | Nicolai Nucleon 16 Mullet (2023) | Nicolai Nucleon 16 Mullet (2023) | Nicolai Nucleon 16 Mullet (2023) | Nicolai Nucleon 16 Mullet (2023) | Nicolai Nucleon 16 Mullet (2023) |
|---|---|---|---|---|---|
| Frame Size/Setup | S | M | L | XL | XXL |
| Typ | Mountainbike | Mountainbike | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | Mullet 29/27,5 | Mullet 29/27,5 | Mullet 29/27,5 | Mullet 29/27,5 | Mullet 29/27,5 |
| Reach | 472 mm | 497 mm | 522 mm | 542 mm | 562 mm |
| Stack | 632 mm | 640 mm | 649 mm | 658 mm | 667 mm |
| STR | 1,34 | 1,29 | 1,24 | 1,21 | 1,19 |
| Front-Center | |||||
| Head Angle | 64.4° | 64.4° | 64.4° | 64.4° | 64.4° |
| Seat Angle, effective | 78.8° | 79° | 79.2° | 79.4° | 79.4° |
| Seat Angle, real | |||||
| Top Tube Length | |||||
| Top Tube Length (horizontal) | 598 mm | 623 mm | 647 mm | 667 mm | 688 mm |
| Head Tube Length | 120 mm | 130 mm | 140 mm | 150 mm | 160 mm |
| Seat Tube Length | 420 mm | 440 mm | 460 mm | 480 mm | 500 mm |
| Standover Height | 644 mm | 664 mm | 678 mm | 700 mm | 718 mm |
| Chainstay Length | 441 mm | 441 mm | 448 mm | 448 mm | 455 mm |
| Wheelbase | 1.252 mm | 1.281 mm | 1.318 mm | 1.342 mm | 1.374 mm |
| Bottom Bracket Drop | 18 mm | 18 mm | 18 mm | 18 mm | 18 mm |
| Bottom Bracket Height | |||||
| Fork installation height | |||||
| Fork offset | |||||
| Fork caster | |||||
| Travel (rear) | |||||
| Travel (front) |
