Moustache Samedi Game (2022) - Geometry
Compare these geometries with each other
Die Tabelle lässt sich verschieben.
| Modell | Moustache Samedi Game (2022) | Moustache Samedi Game (2022) | Moustache Samedi Game (2022) | Moustache Samedi Game (2022) |
|---|---|---|---|---|
| Frame Size/Setup | S | M | L | XL |
| Typ | Mountainbike | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 29″ | 29″ | 29″ | 29″ |
| Reach | 433 mm | 461 mm | 481 mm | 504 mm |
| Stack | 628 mm | 638 mm | 655 mm | 664 mm |
| STR | 1.45 | 1.38 | 1.36 | 1.32 |
| Reach+ | ||||
| Stack+ | ||||
| Frame RAD | 763 mm | 787 mm | 813 mm | 834 mm |
| Frame RAAD | 34.6° | 35.9° | 36.3° | 37.2° |
| Front-Center | ||||
| Head Angle | 65° | 65° | 65° | 65° |
| Seat Angle, effective | 76° | 76° | 76° | 76° |
| Seat Angle, real | ||||
| Top Tube Length | ||||
| Top Tube Length (horizontal) | 590 mm | 620 mm | 645 mm | 670 mm |
| Head Tube Length | 100 mm | 110 mm | 130 mm | 140 mm |
| Seat Tube Length | 390 mm | 420 mm | 450 mm | 490 mm |
| Standover Height | ||||
| Chainstay Length | 462 mm | 462 mm | 462 mm | 462 mm |
| Wheelbase | 1,225 mm | 1,257 mm | 1,286 mm | 1,313 mm |
| FC2RC | 1.65 | 1.72 | 1.78 | 1.84 |
| Bottom Bracket Drop | ||||
| Bottom Bracket Height | ||||
| Fork installation height | 584 mm | 584 mm | 584 mm | 584 mm |
| Fork offset | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | ||||
| Travel (rear) | 160 mm | 160 mm | 160 mm | 160 mm |
| Travel (front) | 170 mm | 170 mm | 170 mm | 170 mm |
