Compare these geometries with each other
| Modell | Mondraker Crusher (2024) | Mondraker Crusher (2024) | Mondraker Crusher (2024) | Mondraker Crusher (2024) |
|---|---|---|---|---|
| Frame Size/Setup | S | M | L | XL |
| Typ | Mountainbike | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 29″ | 29″ | 29″ | 29″ |
| Reach | 450 mm | 470 mm | 490 mm | 510 mm |
| Stack | 632 mm | 632 mm | 645 mm | 645 mm |
| STR | 1,40 | 1,34 | 1,32 | 1,26 |
| Front-Center | ||||
| Head Angle | 65° | 65° | 65° | 65° |
| Seat Angle, effective | 76° | 76° | 76° | 76° |
| Seat Angle, real | 73.5° | 73.5° | 73.5° | 73.5° |
| Top Tube Length | ||||
| Top Tube Length (horizontal) | 605 mm | 625 mm | 650 mm | 670 mm |
| Head Tube Length | 110 mm | 110 mm | 130 mm | 130 mm |
| Seat Tube Length | 380 mm | 420 mm | 450 mm | 490 mm |
| Standover Height | ||||
| Chainstay Length | 455 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1.236 mm | 1.256 mm | 1.285 mm | 1.305 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm | 25 mm |
| Bottom Bracket Height | 350 mm | 350 mm | 350 mm | 350 mm |
| Fork installation height | ||||
| Fork offset | 44 mm | 44 mm | 44 mm | 44 mm |
| Fork caster | ||||
| Travel (rear) | 150 mm | 150 mm | 150 mm | 150 mm |
| Travel (front) | 160 mm | 160 mm | 160 mm | 160 mm |
