Compare these geometries with each other
| Modell | Liteville 4-One MK1 (2020) | Liteville 4-One MK1 (2020) | Liteville 4-One MK1 (2020) | Liteville 4-One MK1 (2020) | Liteville 4-One MK1 (2020) |
|---|---|---|---|---|---|
| Frame Size/Setup | S | M | L | XL | XXL |
| Typ | Gravel-Bike/CycloCross-Bike | Gravel-Bike/CycloCross-Bike | Gravel-Bike/CycloCross-Bike | Gravel-Bike/CycloCross-Bike | Gravel-Bike/CycloCross-Bike |
| Wheel Size | 28″ / 700C | 28″ / 700C | 28″ / 700C | 28″ / 700C | 28″ / 700C |
| Reach | 395 mm | 415 mm | 435 mm | 455 mm | 475 mm |
| Stack | 529.17 mm | 557.37 mm | 585.56 mm | 613.75 mm | 641.94 mm |
| STR | 1,34 | 1,34 | 1,35 | 1,35 | 1,35 |
| Front-Center | |||||
| Head Angle | 70° | 70° | 70° | 70° | 70° |
| Seat Angle, effective | 73° | 73° | 73° | 73° | 73° |
| Seat Angle, real | |||||
| Top Tube Length | 556.78 mm | 585.4 mm | 614.02 mm | 642.64 mm | 671.26 mm |
| Top Tube Length (horizontal) | |||||
| Head Tube Length | 110 mm | 140 mm | 170 mm | 200 mm | 230 mm |
| Seat Tube Length | 441 mm | 465 mm | 489 mm | 513 mm | 537 mm |
| Standover Height | |||||
| Chainstay Length | 415 mm | 420 mm | 425 mm | 430 mm | 435 mm |
| Wheelbase | 1.027 mm | 1.062 mm | 1.098 mm | 1.133 mm | 1.168 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Bottom Bracket Height | |||||
| Fork installation height | 395 mm | 395 mm | 395 mm | 395 mm | 395 mm |
| Fork offset | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm |
| Fork caster | 78.83 mm | 78.83 mm | 78.83 mm | 78.83 mm | 78.83 mm |
| Travel (rear) | |||||
| Travel (front) |
