Compare these geometries with each other
| Modell | Lauf Seigla (2023) | Lauf Seigla (2023) | Lauf Seigla (2023) | Lauf Seigla (2023) | Lauf Seigla (2023) |
|---|---|---|---|---|---|
| Frame Size/Setup | XS | S | M | L | XL |
| Typ | Gravel-Bike/CycloCross-Bike | Gravel-Bike/CycloCross-Bike | Gravel-Bike/CycloCross-Bike | Gravel-Bike/CycloCross-Bike | Gravel-Bike/CycloCross-Bike |
| Wheel Size | 28″ / 700C | 28″ / 700C | 28″ / 700C | 28″ / 700C | 28″ / 700C |
| Reach | 378 mm | 383 mm | 394 mm | 405 mm | 416 mm |
| Stack | 523 mm | 537 mm | 564 mm | 593 mm | 623 mm |
| STR | 1,38 | 1,40 | 1,43 | 1,46 | 1,50 |
| Front-Center | |||||
| Head Angle | 70.5° | 70.5° | 70.5° | 70.5° | 70.5° |
| Seat Angle, effective | |||||
| Seat Angle, real | 72.9° | 72.7° | 72.5° | 72.4° | 72.3° |
| Top Tube Length | 532 mm | 544 mm | 563 mm | 584 mm | 607 mm |
| Top Tube Length (horizontal) | |||||
| Head Tube Length | 84 mm | 99 mm | 129 mm | 159 mm | 191 mm |
| Seat Tube Length | 461 mm | 500 mm | 528 mm | 548 mm | 575 mm |
| Standover Height | |||||
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1.009 mm | 1.020 mm | 1.040 mm | 1.061 mm | 1.084 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Bottom Bracket Height | |||||
| Fork installation height | 419 mm | 419 mm | 419 mm | 419 mm | 419 mm |
| Fork offset | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm |
| Fork caster | |||||
| Travel (rear) | |||||
| Travel (front) |
