Lapierre E-Zesty AM 9.0 (2021) - Geometry

Compare these geometries with each other

The table can be moved.
Modell Lapierre E-Zesty AM 9.0 (2021) Lapierre E-Zesty AM 9.0 (2021) Lapierre E-Zesty AM 9.0 (2021)
Frame Size/Setup M L XL
Typ Mountainbike Mountainbike Mountainbike
Wheel Size 27,5″ / 650B 27,5″ / 650B 27,5″ / 650B
Reach 445 mm 470 mm 495 mm
Stack 607 mm 621 mm 635 mm
STR 1,36 1,32 1,28
Reach+
Stack+
Front-Center
Head Angle 65.5° 65.5° 65.5°
Seat Angle, effective 75° 75° 75°
Seat Angle, real
Top Tube Length 606 mm 636 mm 666 mm
Top Tube Length (horizontal)
Head Tube Length 130 mm 145 mm 160 mm
Seat Tube Length 430 mm 460 mm 500 mm
Standover Height
Chainstay Length 435 mm 435 mm 435 mm
Wheelbase 1.194 mm 1.227 mm 1.259 mm
Bottom Bracket Drop
Bottom Bracket Height
Fork installation height
Fork offset
Fork caster
Travel (rear) 150 mm 150 mm 150 mm
Travel (front) 150 mm 150 mm 150 mm
