Compare these geometries with each other
| Modell | Intense Sniper XC (2022) | Intense Sniper XC (2022) | Intense Sniper XC (2022) | Intense Sniper XC (2022) |
|---|---|---|---|---|
| Frame Size/Setup | S | M | L | XL |
| Typ | Mountainbike | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 29″ | 29″ | 29″ | 29″ |
| Reach | 421 mm | 44.5 mm | 468 mm | 490 mm |
| Stack | 570 mm | 575 mm | 584 mm | 593 mm |
| STR | 1,35 | 12,92 | 1,25 | 1,21 |
| Front-Center | ||||
| Head Angle | 67.5° | 67.5° | 67.5° | 67.5° |
| Seat Angle, effective | 74° | 74° | 74° | 74° |
| Seat Angle, real | ||||
| Top Tube Length | 584 mm | 609 mm | 635 mm | 660 mm |
| Top Tube Length (horizontal) | ||||
| Head Tube Length | 90 mm | 95 mm | 105 mm | 115 mm |
| Seat Tube Length | 406 mm | 437 mm | 488 mm | 538 mm |
| Standover Height | 769 mm | 771 mm | 776 mm | 781 mm |
| Chainstay Length | 439 mm | 439 mm | 439 mm | 439 mm |
| Wheelbase | 1.127 mm | 1.152 mm | 1.179 mm | 1.206 mm |
| Bottom Bracket Drop | 38 mm | 38 mm | 38 mm | 38 mm |
| Bottom Bracket Height | 330 mm | 330 mm | 330 mm | 330 mm |
| Fork installation height | ||||
| Fork offset | 44 mm | 44 mm | 44 mm | 44 mm |
| Fork caster | ||||
| Travel (rear) | 100 mm | 100 mm | 100 mm | 100 mm |
| Travel (front) | 100 mm | 100 mm | 100 mm | 100 mm |
