Compare these geometries with each other
| Modell | Instinctiv M7 (2021) | Instinctiv M7 (2021) | Instinctiv M7 (2021) |
|---|---|---|---|
| Frame Size/Setup | M | L | XL |
| Typ | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 27,5″ / 650B | 27,5″ / 650B | 27,5″ / 650B |
| Reach | 452 mm | 486 mm | 518 mm |
| Stack | 615 mm | 624 mm | 637 mm |
| STR | 1,36 | 1,28 | 1,23 |
| Front-Center | |||
| Head Angle | 64.5° | 64.5° | 64.5° |
| Seat Angle, effective | 76° | 76° | 76° |
| Seat Angle, real | |||
| Top Tube Length | 605 mm | 642 mm | 678 mm |
| Top Tube Length (horizontal) | |||
| Head Tube Length | 110 mm | 120 mm | 135 mm |
| Seat Tube Length | 430 mm | 460 mm | 460 mm |
| Standover Height | 688 mm | 720 mm | 719 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1.216 mm | 1.254 mm | 1.293 mm |
| Bottom Bracket Drop | 16.5 mm | 16.5 mm | 16.5 mm |
| Bottom Bracket Height | 339 mm | 339 mm | 339 mm |
| Fork installation height | |||
| Fork offset | |||
| Fork caster | |||
| Travel (rear) | 150 mm | 150 mm | 150 mm |
| Travel (front) | 160 mm | 160 mm | 160 mm |
