Compare these geometries with each other
| Modell | Ibis Hakka MX (2020) | Ibis Hakka MX (2020) | Ibis Hakka MX (2020) | Ibis Hakka MX (2020) | Ibis Hakka MX (2020) |
|---|---|---|---|---|---|
| Frame Size/Setup | 49 | 53 | 55 | 58 | 61 |
| Typ | Gravel-Bike/CycloCross-Bike | Gravel-Bike/CycloCross-Bike | Gravel-Bike/CycloCross-Bike | Gravel-Bike/CycloCross-Bike | Gravel-Bike/CycloCross-Bike |
| Wheel Size | 28″ / 700C | 28″ / 700C | 28″ / 700C | 28″ / 700C | 28″ / 700C |
| Reach | 370 mm | 373 mm | 382 mm | 391 mm | 406 mm |
| Stack | 532 mm | 560 mm | 580 mm | 599 mm | 616 mm |
| STR | 1,44 | 1,50 | 1,52 | 1,53 | 1,52 |
| Front-Center | |||||
| Head Angle | 70.5° | 71.5° | 72° | 72° | 72° |
| Seat Angle, effective | |||||
| Seat Angle, real | 74.5° | 73.5° | 73.5° | 73.5° | 73.5° |
| Top Tube Length | |||||
| Top Tube Length (horizontal) | 520 mm | 540 mm | 550 mm | 570 mm | 590 mm |
| Head Tube Length | 110 mm | 135 mm | 155 mm | 175 mm | 195 mm |
| Seat Tube Length | 455 mm | 525 mm | 550 mm | 575 mm | 605 mm |
| Standover Height | 729 mm | 785 mm | 802 mm | 827 mm | 853 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1.007 mm | 1.011 mm | 1.021 mm | 1.037 mm | 1.057 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Bottom Bracket Height | |||||
| Fork installation height | |||||
| Fork offset | |||||
| Fork caster | |||||
| Travel (rear) | |||||
| Travel (front) |
