Compare these geometries with each other
| Modell | Hope HB.130 (Standard Version) (2021) | Hope HB.130 (Standard Version) (2021) | Hope HB.130 (Standard Version) (2021) |
|---|---|---|---|
| Frame Size/Setup | M | L | XL |
| Typ | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 29″ 29″ | 29″ 29″ | 29″ 29″ |
| Reach | 449.5 mm 455 mm | 469.5 mm 475 mm | 489.5 mm 495 mm |
| Stack | |||
| STR | |||
| Front-Center | |||
| Head Angle | 66° 66.5° | 66° 66.5° | 66° 66.5° |
| Seat Angle, effective | 76.2° 76.7° | 75.7° 76.2° | 75.2° 75.7° |
| Seat Angle, real | |||
| Top Tube Length | |||
| Top Tube Length (horizontal) | 600 mm 600 mm | 627 mm 627 mm | 654 mm 654 mm |
| Head Tube Length | 100 mm 100 mm | 105 mm 105 mm | 110 mm 110 mm |
| Seat Tube Length | 415 mm 415 mm | 440 mm 440 mm | 480 mm 480 mm |
| Standover Height | |||
| Chainstay Length | 435 mm 435 mm | 435 mm 435 mm | 435 mm 435 mm |
| Wheelbase | 1.192 mm 1.191 mm | 1.214 mm 1.213 mm | 1.236 mm 1.235 mm |
| Bottom Bracket Drop | 39.5 mm 33 mm | 39.5 mm 33 mm | 39.5 mm 33 mm |
| Bottom Bracket Height | |||
| Fork installation height | |||
| Fork offset | 44 mm 44 mm | 44 mm 44 mm | 44 mm 44 mm |
| Fork caster | |||
| Travel (rear) | 130 mm 130 mm | 130 mm 130 mm | 130 mm 130 mm |
| Travel (front) | 140 mm 140 mm | 140 mm 140 mm | 140 mm 140 mm |
