Compare these geometries with each other
| Modell | GT Bicycles Force Carbon (2022) | GT Bicycles Force Carbon (2022) | GT Bicycles Force Carbon (2022) | GT Bicycles Force Carbon (2022) |
|---|---|---|---|---|
| Frame Size/Setup | S | M | L | XL |
| Typ | Mountainbike | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 29″ 29″ | 29″ 29″ | 29″ 29″ | 29″ 29″ |
| Reach | 430 mm 430 mm | 455 mm 455 mm | 480 mm 480 mm | 515 mm 515 mm |
| Stack | 627 mm 627 mm | 636 mm 636 mm | 645 mm 645 mm | 654 mm 654 mm |
| STR | 1,46 1,46 | 1,40 1,40 | 1,34 1,34 | 1,27 1,27 |
| Front-Center | ||||
| Head Angle | 63.5° 63.5° | 63.5° 63.5° | 63.5° 63.5° | 63.5° 63.5° |
| Seat Angle, effective | 78° 78° | 78° 78° | 78° 78° | 78° 78° |
| Seat Angle, real | ||||
| Top Tube Length | 544 mm 544 mm | 565 mm 565 mm | 586 mm 586 mm | 620 mm 620 mm |
| Top Tube Length (horizontal) | 563 mm 563 mm | 590 mm 590 mm | 617 mm 617 mm | 654 mm 654 mm |
| Head Tube Length | 110 mm 110 mm | 120 mm 120 mm | 130 mm 130 mm | 140 mm 140 mm |
| Seat Tube Length | 380 mm 380 mm | 410 mm 410 mm | 445 mm 445 mm | 500 mm 500 mm |
| Standover Height | 725 mm 725 mm | 730 mm 730 mm | 740 mm 740 mm | 760 mm 760 mm |
| Chainstay Length | 435 mm 445 mm | 435 mm 445 mm | 435 mm 445 mm | 435 mm 445 mm |
| Wheelbase | 1.211 mm 1.221 mm | 1.240 mm 1.250 mm | 1.270 mm 1.280 mm | 1.309 mm 1.319 mm |
| Bottom Bracket Drop | 30 mm 30 mm | 30 mm 30 mm | 30 mm 30 mm | 30 mm 30 mm |
| Bottom Bracket Height | 347 mm 347 mm | 347 mm 347 mm | 347 mm 347 mm | 347 mm 347 mm |
| Fork installation height | ||||
| Fork offset | 44 mm 44 mm | 44 mm 44 mm | 44 mm 44 mm | 44 mm 44 mm |
| Fork caster | ||||
| Travel (rear) | 160 mm 160 mm | 160 mm 160 mm | 160 mm 160 mm | 160 mm 160 mm |
| Travel (front) | 170 mm 170 mm | 170 mm 170 mm | 170 mm 170 mm | 170 mm 170 mm |
