Compare these geometries with each other
| Modell | Giant Trance X 29 (2021) | Giant Trance X 29 (2021) | Giant Trance X 29 (2021) | Giant Trance X 29 (2021) |
|---|---|---|---|---|
| Frame Size/Setup | S | M | L | XL |
| Typ | Mountainbike | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 29″ 29″ | 29″ 29″ | 29″ 29″ | 29″ 29″ |
| Reach | 434 mm 426 mm | 464 mm 456 mm | 494 mm 486 mm | 519 mm 510 mm |
| Stack | 611 mm 617 mm | 615 mm 621 mm | 624 mm 631 mm | 634 mm 640 mm |
| STR | 1,41 1,45 | 1,33 1,36 | 1,26 1,30 | 1,22 1,25 |
| Front-Center | ||||
| Head Angle | 66.23° 65.5° | 66.23° 65.5° | 66.23° 65.5° | 66.23° 65.5° |
| Seat Angle, effective | 77.93° 77.2° | 77.93° 77.2° | 77.93° 77.2° | 77.93° 77.2° |
| Seat Angle, real | ||||
| Top Tube Length | 564 mm 566 mm | 595 mm 597 mm | 627 mm 629 mm | 654 mm 656 mm |
| Top Tube Length (horizontal) | ||||
| Head Tube Length | 95 mm 95 mm | 100 mm 100 mm | 110 mm 110 mm | 120 mm 120 mm |
| Seat Tube Length | 430 mm 430 mm | 430 mm 430 mm | 465 mm 465 mm | 496 mm 496 mm |
| Standover Height | ||||
| Chainstay Length | 435 mm 438 mm | 435 mm 438 mm | 435 mm 438 mm | 435 mm 438 mm |
| Wheelbase | 1.171 mm 1.173 mm | 1.203 mm 1.205 mm | 1.238 mm 1.239 mm | 1.266 mm 1.268 mm |
| Bottom Bracket Drop | 30 mm 40 mm | 30 mm 40 mm | 30 mm 40 mm | 30 mm 40 mm |
| Bottom Bracket Height | ||||
| Fork installation height | ||||
| Fork offset | 44 mm 44 mm | 44 mm 44 mm | 44 mm 44 mm | 44 mm 44 mm |
| Fork caster | ||||
| Travel (rear) | ||||
| Travel (front) |
