Ghost E-Riot (2021) - Geometry

Compare these geometries with each other

The table can be moved.
Modell Ghost E-Riot (2021) Ghost E-Riot (2021) Ghost E-Riot (2021) Ghost E-Riot (2021)
Frame Size/Setup S M L XL
Typ Mountainbike Mountainbike Mountainbike Mountainbike
Wheel Size 27,5″ / 650B 29″ 29″ 29″
Reach 449 mm 467 mm 487 mm 516 mm
Stack 587 mm 615 mm 652 mm 670 mm
STR 1,31 1,32 1,34 1,30
Reach+
Stack+
Front-Center
Head Angle 66° 66° 66° 66°
Seat Angle, effective 76° 77° 77° 77°
Seat Angle, real
Top Tube Length 588 mm 648 mm 683 mm 684 mm
Top Tube Length (horizontal)
Head Tube Length 100 mm 100 mm 140 mm 160 mm
Seat Tube Length 417 mm 441 mm 465 mm 489 mm
Standover Height 772 mm 800 mm 803 mm 802 mm
Chainstay Length 430 mm 450 mm 450 mm 450 mm
Wheelbase 1.180 mm 1.230 mm 1.266 mm 1.303 mm
Bottom Bracket Drop 25 mm 39 mm 39 mm 39 mm
Bottom Bracket Height
Fork installation height
Fork offset
Fork caster
Travel (rear) 140 mm 140 mm 140 mm 140 mm
Travel (front) 150 mm 150 mm 150 mm 150 mm
