Compare these geometries with each other
| Modell | Forestal Cyon (2021) | Forestal Cyon (2021) | Forestal Cyon (2021) | Forestal Cyon (2021) |
|---|---|---|---|---|
| Frame Size/Setup | S | M | L | XL |
| Typ | Mountainbike | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 29″ | 29″ | 29″ | 29″ |
| Reach | 430 mm | 455 mm | 480 mm | 500 mm |
| Stack | 611 mm | 616 mm | 625 mm | 638 mm |
| STR | 1,42 | 1,35 | 1,30 | 1,28 |
| Front-Center | ||||
| Head Angle | 65.5° | 65.5° | 65.5° | 65.5° |
| Seat Angle, effective | 76.5° | 76.5° | 76.5° | 76.5° |
| Seat Angle, real | ||||
| Top Tube Length | ||||
| Top Tube Length (horizontal) | 577 mm | 603 mm | 633 mm | 657 mm |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 125 mm |
| Seat Tube Length | 415 mm | 430 mm | 465 mm | 500 mm |
| Standover Height | ||||
| Chainstay Length | 435 mm | 435 mm | 445 mm | 445 mm |
| Wheelbase | 1.176 mm | 1.203 mm | 1.242 mm | 1.268 mm |
| Bottom Bracket Drop | -30 mm | -30 mm | -30 mm | -30 mm |
| Bottom Bracket Height | 346 mm | 346 mm | 346 mm | 346 mm |
| Fork installation height | ||||
| Fork offset | 42 mm | 42 mm | 42 mm | 42 mm |
| Fork caster | ||||
| Travel (rear) | 150 mm | 150 mm | 150 mm | 150 mm |
| Travel (front) | 150 mm | 150 mm | 150 mm | 150 mm |
