Factor Lando HT (2022) - Geometry
Compare these geometries with each other
Die Tabelle lässt sich verschieben.
| Modell | Factor Lando HT (2022) | Factor Lando HT (2022) | Factor Lando HT (2022) | Factor Lando HT (2022) |
|---|---|---|---|---|
| Frame Size/Setup | Large | Medium | Small | X-Small |
| Typ | Mountainbike | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 29″ | 29″ | 29″ | 29″ |
| Reach | 476 mm | 445 mm | 415 mm | 394 mm |
| Stack | 633 mm | 618.5 mm | 613.5 mm | 609 mm |
| STR | 1.33 | 1.39 | 1.48 | 1.55 |
| Reach+ | ||||
| Stack+ | ||||
| Frame RAD | 792 mm | 762 mm | 741 mm | 725 mm |
| Frame RAAD | 36.9° | 35.7° | 34.1° | 32.9° |
| Front-Center | ||||
| Head Angle | 68.5° | 68.5° | 68.5° | 68.5° |
| Seat Angle, effective | 73.5° | 73.5° | 74° | 74.5° |
| Seat Angle, real | ||||
| Top Tube Length | ||||
| Top Tube Length (horizontal) | ||||
| Head Tube Length | ||||
| Seat Tube Length | ||||
| Standover Height | ||||
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1,184 mm | 1,147 mm | 1,115 mm | 1,092 mm |
| FC2RC | 1.75 | 1.67 | 1.59 | 1.54 |
| Bottom Bracket Drop | 54.5 mm | 54.5 mm | 56.5 mm | 56.5 mm |
| Bottom Bracket Height | ||||
| Fork installation height | 517 mm | 517 mm | 517 mm | 517 mm |
| Fork offset | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | ||||
| Travel (rear) | ||||
| Travel (front) | 110 mm | 110 mm | 110 mm | 110 mm |
