Compare these geometries with each other
| Modell | Devinci E-Spartan (2022) | Devinci E-Spartan (2022) | Devinci E-Spartan (2022) | Devinci E-Spartan (2022) |
|---|---|---|---|---|
| Frame Size/Setup | S | M | L | XL |
| Typ | Mountainbike | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 29″ | 29″ | 29″ | 29″ |
| Reach | 440 mm | 460 mm | 485 mm | 505 mm |
| Stack | 625 mm | 634 mm | 643 mm | 652 mm |
| STR | 1,42 | 1,38 | 1,33 | 1,29 |
| Front-Center | ||||
| Head Angle | 64° | 64° | 64° | 64° |
| Seat Angle, effective | 77.3° | 77.2° | 77.1° | 77° |
| Seat Angle, real | ||||
| Top Tube Length | ||||
| Top Tube Length (horizontal) | 581 mm | 604 mm | 633 mm | 656 mm |
| Head Tube Length | 95 mm | 105 mm | 115 mm | 125 mm |
| Seat Tube Length | 400 mm | 420 mm | 445 mm | 485 mm |
| Standover Height | 733 mm | 745 mm | 763 mm | 785 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1.236 mm | 1.260 mm | 1.290 mm | 1.314 mm |
| Bottom Bracket Drop | ||||
| Bottom Bracket Height | 354 mm | 354 mm | 354 mm | 354 mm |
| Fork installation height | ||||
| Fork offset | 44 mm | 44 mm | 44 mm | 44 mm |
| Fork caster | ||||
| Travel (rear) | 170 mm | 170 mm | 170 mm | 170 mm |
| Travel (front) | 180 mm | 180 mm | 180 mm | 180 mm |
