Compare these geometries with each other
| Modell | Deviate Highlander 140 (2020) | Deviate Highlander 140 (2020) | Deviate Highlander 140 (2020) |
|---|---|---|---|
| Frame Size/Setup | M | L | XL |
| Typ | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 29″ | 29″ | 29″ |
| Reach | 444 mm | 473 mm | 499 mm |
| Stack | 613 mm | 623 mm | 641 mm |
| STR | 1,38 | 1,32 | 1,28 |
| Front-Center | |||
| Head Angle | 66° | 66° | 66° |
| Seat Angle, effective | 76° | 76° | 76° |
| Seat Angle, real | |||
| Top Tube Length | |||
| Top Tube Length (horizontal) | |||
| Head Tube Length | 100 mm | 110 mm | 130 mm |
| Seat Tube Length | 410 mm | 430 mm | 450 mm |
| Standover Height | 730 mm | 730 mm | 745 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1.194 mm | 1.228 mm | 1.261 mm |
| Bottom Bracket Drop | 28 mm | 28 mm | 28 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm |
| Fork installation height | 561 mm | 561 mm | 561 mm |
| Fork offset | 44 mm | 44 mm | 44 mm |
| Fork caster | |||
| Travel (rear) | 140 mm | 140 mm | 140 mm |
| Travel (front) | 150 mm | 150 mm | 150 mm |
