Compare these geometries with each other
| Modell | Cube Stereo Hybrid 160 HPC (2022) | Cube Stereo Hybrid 160 HPC (2022) | Cube Stereo Hybrid 160 HPC (2022) |
|---|---|---|---|
| Frame Size/Setup | M | L | XL |
| Typ | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 27,5″ / 650B | 27,5″ / 650B | 27,5″ / 650B |
| Reach | 453.4 mm | 479.8 mm | 504.5 mm |
| Stack | 616.1 mm | 626.9 mm | 643.3 mm |
| STR | 1,36 | 1,31 | 1,28 |
| Front-Center | |||
| Head Angle | 65° | 65° | 65° |
| Seat Angle, effective | 76° | 76° | 76° |
| Seat Angle, real | |||
| Top Tube Length | |||
| Top Tube Length (horizontal) | 600 mm | 630 mm | 660 mm |
| Head Tube Length | 120 mm | 132 mm | 150 mm |
| Seat Tube Length | 420 mm | 460 mm | 490 mm |
| Standover Height | 769.9 mm | 769.3 mm | 792.6 mm |
| Chainstay Length | 441.5 mm | 441.5 mm | 441.5 mm |
| Wheelbase | 1.224 mm | 1.256 mm | 1.288 mm |
| Bottom Bracket Drop | 12.5 mm | 12.6 mm | 12.7 mm |
| Bottom Bracket Height | |||
| Fork installation height | |||
| Fork offset | |||
| Fork caster | |||
| Travel (rear) | 160 mm | 160 mm | 160 mm |
| Travel (front) | 160 mm | 160 mm | 160 mm |
