Compare these geometries with each other
| Modell | Cube Stereo Hybrid 140 HPC (2022) | Cube Stereo Hybrid 140 HPC (2022) | Cube Stereo Hybrid 140 HPC (2022) |
|---|---|---|---|
| Frame Size/Setup | M | L | XL |
| Typ | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 29″ | 29″ | 29″ |
| Reach | 446.8 mm | 472.8 mm | 496.8 mm |
| Stack | 625.5 mm | 636.5 mm | 652.9 mm |
| STR | 1,40 | 1,35 | 1,31 |
| Front-Center | |||
| Head Angle | 66° | 66° | 66° |
| Seat Angle, effective | 75.5° | 75.5° | 75.5° |
| Seat Angle, real | |||
| Top Tube Length | |||
| Top Tube Length (horizontal) | 600 mm | 630 mm | 660 mm |
| Head Tube Length | 108 mm | 120 mm | 138 mm |
| Seat Tube Length | 420 mm | 460 mm | 490 mm |
| Standover Height | 764.4 mm | 762.6 mm | 784.6 mm |
| Chainstay Length | 457 mm | 457 mm | 457 mm |
| Wheelbase | 1.220 mm | 1.251 mm | 1.282 mm |
| Bottom Bracket Drop | 36 mm | 36 mm | 36 mm |
| Bottom Bracket Height | |||
| Fork installation height | |||
| Fork offset | |||
| Fork caster | |||
| Travel (rear) | 140 mm | 140 mm | 140 mm |
| Travel (front) | 140 mm | 140 mm | 140 mm |
