Cube Elite 240 (2022) - Geometry

Compare these geometries with each other

The table can be moved.
Modell Cube Elite 240 (2022)
Frame Size/Setup Einheitsgröße
Typ Mountainbike
Wheel Size 24″
Reach 361.6 mm
Stack 507.9 mm
STR 1,40
Head Angle 69°
Seat Angle, effective 73.5°
Seat Angle, real
Top Tube Length
Top Tube Length (horizontal) 512 mm
Head Tube Length 95 mm
Seat Tube Length 300 mm
Standover Height 605 mm
Chainstay Length 380 mm
Wheelbase 959.6 mm
Bottom Bracket Drop 45 mm
Bottom Bracket Height
Fork installation height
Fork offset
Fork caster
Travel (rear)
Travel (front)
